AQF1000-48S
ActiveARCH Electronics Corp
AC/DC CONVERTER 48V 1000W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
AQF1000-48S
ActiveARCH Electronics Corp
AC/DC CONVERTER 48V 1000W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | AQF1000-48S |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | CB, cURus, CE |
| Current - Output 1 | 20.84 A |
| Efficiency | 93 % |
| Features | Universal Input |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -20 °C |
| Power (Watts) | 1 kW |
| Size / Dimension [x] | 7.66 in |
| Size / Dimension [x] | 194.6 mm |
| Size / Dimension [y] | 102.1 mm |
| Size / Dimension [y] | 4.02 in |
| Size / Dimension [z] | 41.1 mm |
| Size / Dimension [z] | 1.62 in |
| Standard Number | 62368-1 |
| Type | Enclosed |
| Voltage - Input [Max] | 264 VAC |
| Voltage - Input [Min] | 90 VAC |
| Voltage - Isolation | 4.3 kV |
| Voltage - Output 1 | 48 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
AQF1000-48S
Enclosed AC DC Converters 1 Output 48V 90 ~ 264 VAC Input
