CDB260W-1300-280-W
ActiveERP Power, LLC
LED DRVR CC AC/DC 260W DIM
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
CDB260W-1300-280-W
ActiveERP Power, LLC
LED DRVR CC AC/DC 260W DIM
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | CDB260W-1300-280-W |
|---|---|
| Approval Agency | CE, CB, cULus |
| Current - Output (Max) | 1.3 A, 930 mA |
| Dimming | Bluetooth, Analog |
| Efficiency | 93 % |
| Features | OTP, SCP, OCP |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Power (Watts) | 260 W |
| Ratings | IP66 |
| Size / Dimension [x] | 216.9 mm |
| Size / Dimension [x] | 8.54 in |
| Size / Dimension [y] | 2 in |
| Size / Dimension [y] | 50.8 mm |
| Size / Dimension [z] | 1.52 in |
| Size / Dimension [z] | 38.6 mm |
| Termination Style | Wire Leads |
| Topology | AC DC Converter |
| Type | Constant Current |
| Voltage - Input (Max) [Max] | 305 VAC |
| Voltage - Input (Min) [Min] | 90 VAC |
| Voltage - Output [Max] | 280 V, 200 V |
| Voltage - Output [Min] | 213 V, 152 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 108.36 | |
| 5 | $ 105.07 | |||
Description
General part information
CDB260W-1300-280-W
930mA, 1.3A 213 ~ 280V, 152 ~ 200V Constant Current LED Driver AC DC Converter Topology 1 Output
