R-F1KR080400000
ActiveNextron
1K, FIXED SOCKET, 8PIN, IP68
Deep-Dive with AI
Search across all available documentation for this part.
R-F1KR080400000
ActiveNextron
1K, FIXED SOCKET, 8PIN, IP68
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | R-F1KR080400000 |
|---|---|
| Backshell Material, Plating | Copper Alloy, Nickel |
| Color | Silver |
| Connector Type | Receptacle, Female Sockets |
| Contact Finish - Mating | Gold |
| Contact Material | Copper Alloy |
| Current Rating (Amps) | 5 A |
| Fastening Type | Detent Lock, Push-Pull |
| Ingress Protection | IP66/IP68 |
| Insert Material | Polyetheretherketone (PEEK) |
| Material Flammability Rating | UL94 V-0 |
| Mounting Feature | Bulkhead - Rear Side Nut |
| Number of Positions | 8 |
| Operating Temperature [Max] | 200 °C |
| Operating Temperature [Min] | -55 °C |
| Orientation | 0 ° |
| Primary Material | Metal |
| Shell Finish | Nickel |
| Shell Material | Copper Alloy |
| Shell Size - Insert | 1K |
| Shielding | Unshielded |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bag | 1 | $ 30.63 | |
| 2 | $ 30.62 | |||
| 10 | $ 28.70 | |||
| 20 | $ 27.01 | |||
Description
General part information
R-F1KR080400000
8 Position Circular Connector Receptacle, Female Sockets Solder Cup
