SCA240DA160
ActiveSanRex Corporation
THYRISTOR MODULE 1600V 240A
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
SCA240DA160
ActiveSanRex Corporation
THYRISTOR MODULE 1600V 240A
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | SCA240DA160 |
|---|---|
| Current - Gate Trigger (Igt) (Max) [Max] [x] | 100 mA |
| Current - Hold (Ih) (Max) [Max] | 140 mA |
| Current - Non Rep. Surge 50, 60Hz (Itsm) [Max] | 6500 A |
| Current - Non Rep. Surge 50, 60Hz (Itsm) [Min] | 6000 A |
| Current - On State (It (AV)) (Max) [Max] | 240 A |
| Current - On State (It (RMS)) (Max) | 376 A |
| Mounting Type | Chassis Mount |
| Number of SCRs, Diodes | 2 SCRs |
| Operating Temperature [Max] | 125 ¯C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Module |
| Structure | Series Connection - All SCRs |
| Voltage - Off State | 1.6 kV |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 6 | $ 121.30 | |
| 10 | $ 112.29 | |||
| 25 | $ 108.19 | |||
| 80 | $ 103.27 | |||
Description
General part information
SCA240DA160
SCR Module 1.6 kV 376 A Series Connection - All SCRs Chassis Mount Module
