SDS802X HD
ActiveSiglent Technologies NA, Inc.
OSCILLOSCOPE 12BIT 2 CH 70 MHZ
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
SDS802X HD
ActiveSiglent Technologies NA, Inc.
OSCILLOSCOPE 12BIT 2 CH 70 MHZ
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | SDS802X HD |
|---|---|
| Bandwidth | 70 MHz |
| Channels | 2 Analog |
| Display Type | TFT - Color (Touch) |
| Function | Save, Playback, Record |
| Includes | USB Cable, Power Cord, Passive Probes |
| Input Impedance | 17 pF, 1 M |
| Interface | USB, LAN |
| Memory Size | 50 Mpts |
| Probe Type | Passive 10:1 (5) |
| Rise Time (Typ) | 5 ns |
| Sampling Rate (Per Second) | 2 G |
| Type | Bench |
| Voltage - Input (Max) [Max] | 400 V |
| Voltage - Supply [Max] | 240 VAC |
| Voltage - Supply [Min] | 100 VAC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 339.00 | |
Description
General part information
SDS802X HD
70 MHz Bench Oscilloscopes LAN, USB Interface TFT - Color (Touch) Display 2 Analog Channel 400V Record, Playback, Save
