TB1-20A080H
ActiveDIT
LINE FILTER 250VAC/VDC 20A CHASS
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
TB1-20A080H
ActiveDIT
LINE FILTER 250VAC/VDC 20A CHASS
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | TB1-20A080H |
|---|---|
| Applications | General Purpose |
| Approval Agency | CE, cCSAus, SEMKO, ENEC |
| Configuration | Two Stage |
| Current | 20 A |
| Filter Type | Single Phase |
| Frequency - Operating [Max] | 60 Hz |
| Frequency - Operating [Min] | 50 Hz |
| Mounting Type | Chassis Mount |
| Operating Temperature [custom] | 100 °C, -25 °C |
| Termination Style | Terminal Block |
| Voltage - Rated AC | 250 V |
| Voltage - Rated DC | 250 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 38.45 | |
| 10 | $ 32.68 | |||
| 25 | $ 30.63 | |||
| 50 | $ 29.17 | |||
| 100 | $ 27.78 | |||
| 250 | $ 26.04 | |||
Description
General part information
TB1-20A080H
Single Phase EMC/EMI Line Filter 20 A 250V 250V 50 ~ 60Hz Two Stage Terminal Block
