SK513-T605Q04
Active7STARLAKE
COME T6, I7-9850HL, RTX5000
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
SK513-T605Q04
Active7STARLAKE
COME T6, I7-9850HL, RTX5000
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | SK513-T605Q04 |
|---|---|
| Cooling Type | Heat Sink |
| Core Processor | Intel Core i7-9850HL |
| Ethernet | 10 Mbps, 1000 Mbps, 100 Mbps |
| Ethernet | RJ45 (2) |
| Expansion Site/Bus | LPC, PCIe/104, mSATA, M.2, Audio, Mini-PCIe |
| Form Factor | COM Express 2.1 |
| Number of Cores | 6 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Power (Watts) | 25 W |
| RAM Capacity/Installed | 96 GB, 0 GB |
| RS-232 (422, 485) | 4 |
| Size / Dimension [x] | 189.99 mm |
| Size / Dimension [x] | 7.48 " |
| Size / Dimension [y] | 7.28 in |
| Size / Dimension [y] | 184.91 mm |
| Speed | 4.1 GHz |
| Storage Interface | SATA 3.0 (2) |
| USB | USB 3.0 (4), USB 2.0 (2) |
| Video Outputs | LVDS, DP (2), VGA, DVI |
| Watchdog Timer | False |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 12080.00 | |
Description
General part information
SK513-T605Q04
Single Board Computer 4.1GHz 6 Core 96GB/0GB RAM Intel Core i7-9850HL
Documents
Technical documentation and resources
