AT24MAC602-XHM-B
ActiveAtmel
IC EEPROM 2KBIT I2C 1MHZ 8TSSOP
Deep-Dive with AI
Search across all available documentation for this part.
AT24MAC602-XHM-B
ActiveAtmel
IC EEPROM 2KBIT I2C 1MHZ 8TSSOP
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | AT24MAC602-XHM-B |
|---|---|
| Access Time | 550 ns |
| Memory Format | EEPROM |
| Memory Interface | I2C |
| Memory Organization [custom] | 8 |
| Memory Organization [custom] | 256 |
| Memory Size | 256 B |
| Memory Type | Non-Volatile |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 8-TSSOP |
| Package / Case [custom] | 0.173 " |
| Package / Case [custom] | 4.4 mm |
| Supplier Device Package | 8-TSSOP |
| Technology | EEPROM |
| Voltage - Supply [Max] | 5.5 V |
| Voltage - Supply [Min] | 1.7 V |
| Write Cycle Time - Word, Page | 5 ms |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 770 | $ 0.39 | |
| Tube | 1000 | $ 0.37 | ||
Description
General part information
AT24MAC602-XHM-B
EEPROM Memory IC 2Kbit I2C 1 MHz 550 ns 8-TSSOP
Documents
Technical documentation and resources
No documents available
