IT6942A
ActiveITECH ELECTRONIC CO.,LTD.
POWER SUPPLY 360W/30V AUTO-RANGE
Deep-Dive with AI
Search across all available documentation for this part.
IT6942A
ActiveITECH ELECTRONIC CO.,LTD.
POWER SUPPLY 360W/30V AUTO-RANGE
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | IT6942A |
|---|---|
| Accuracy - Voltmeter; Ammeter | 0.1% + 15mA, 0.03% + 5mV |
| Current - Output [Max] | 15 A |
| Current - Output [Min] | 0 A |
| Current Regulation - Load | 0.05 %, 6 mA |
| Display Type | VFD |
| Features | Programmable |
| Number of Characters | 12 |
| Number of Outputs | 2 |
| Power (Watts) | 360 W |
| Ripple | 15 mV |
| Size / Dimension [x] | 345 mm |
| Size / Dimension [x] | 13.583 " |
| Size / Dimension [y] | 8.445 in |
| Size / Dimension [y] | 214.5 mm |
| Size / Dimension [z] | 88.2 mm |
| Size / Dimension [z] | 3.472 in |
| Type | Bench (AC to DC) |
| Voltage - Output [Max] | 60 VDC |
| Voltage - Output [Min] | 0 VDC |
| Voltage Regulation - Load | 30 mV, 0.01 % |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 837.16 | |
| 5 | $ 799.01 | |||
| 10 | $ 783.11 | |||
Description
General part information
IT6942A
0 ~ 60V Output Bench (AC to DC) Power Supply VFD 0 ~ 15A Output 360W Features Programmable
