B2841USD-20D001014U1930
ActiveHarvatek Corporation
LED RED DIFFUSED 0402 SMD
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
B2841USD-20D001014U1930
ActiveHarvatek Corporation
LED RED DIFFUSED 0402 SMD
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | B2841USD-20D001014U1930 |
|---|---|
| Color | Red |
| Current - Test | 20 mA |
| Height (Max) [Max] | 0.6 mm |
| Lens Size [x] | 1 mm |
| Lens Size [y] | 0.5 mm |
| Lens Style | Rectangle with Flat Top |
| Lens Transparency | Diffused |
| Millicandela Rating | 112.5 mcd |
| Mounting Type | Surface Mount |
| Package / Case | 0402 (1005 Metric) |
| Size / Dimension [x] | 1 mm |
| Size / Dimension [y] | 0.5 mm |
| Supplier Device Package | 0402 |
| Viewing Angle | 120 °, 128 ° |
| Voltage - Forward (Vf) (Typ) | 2 V |
| Wavelength - Dominant | 624 nm |
| Wavelength - Peak | 632 nm |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 0.10 | |
| 10 | $ 0.06 | |||
| Digi-Reel® | 1 | $ 0.10 | ||
| 10 | $ 0.06 | |||
| Tape & Reel (TR) | 4000 | $ 0.06 | ||
Description
General part information
B2841USD-20D001014U1930
Red 624nm LED Indication - Discrete 2V 0402 (1005 Metric)
