PT30-100PSIG-1-1-2-8
ActiveNOSHOK
PRESSURE TRANSMITTER, GAUGE, 0 TO 100PSI
Deep-Dive with AI
Search across all available documentation for this part.
PT30-100PSIG-1-1-2-8
ActiveNOSHOK
PRESSURE TRANSMITTER, GAUGE, 0 TO 100PSI
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | PT30-100PSIG-1-1-2-8 |
|---|---|
| Accuracy | 0.25 % |
| Applications | Industrial Automation |
| Features | Temperature Compensated |
| Maximum Pressure [Max] | 2068.43 kPa |
| Maximum Pressure [Max] | 300 PSI |
| Operating Pressure | 689.48 kPa |
| Operating Pressure | 100 PSI |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -20 C |
| Output [Max] | 20 mA |
| Output [Min] | 4 mA |
| Output Type | Analog Current |
| Package / Case | Cylinder, Threaded |
| Port Size [custom] | NPT |
| Port Size [custom] | Male |
| Port Size [x] | 0.25 " |
| Port Size [x] | 6.35 mm |
| Port Style | Threaded |
| Pressure Type | Gauge |
| Termination Style | Connector |
| Voltage - Supply [Max] | 36 V |
| Voltage - Supply [Min] | 12 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
PT30-100PSIG-1-1-2-8
PT30-100psig-1-1-2-8 is a PT30 series high performance fixed range pressure transmitter. Typical applications include hydraulics & pneumatics, automotive, pumps & compressors, refrigeration controls, mobile equipment and general industrial.
