UIA700-15S
ActiveDaburn
AC/DC CONVERTER 15V 625W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
UIA700-15S
ActiveDaburn
AC/DC CONVERTER 15V 625W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | UIA700-15S |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | CB, cURus, CE |
| Current - Output 1 | 42 A |
| Efficiency | 90 % |
| Features | Adjustable Output |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -30 °C |
| Power (Watts) | 625 W |
| Size / Dimension [x] | 168.9 mm |
| Size / Dimension [x] | 6.65 in |
| Size / Dimension [y] | 3.66 in |
| Size / Dimension [y] | 93 mm |
| Size / Dimension [z] | 40.9 mm |
| Size / Dimension [z] | 1.61 " |
| Standard Number | 62368-1 |
| Type | Enclosed |
| Voltage - Input [Max] | 264 VAC |
| Voltage - Input [Min] | 90 VAC |
| Voltage - Isolation | 5.656 kV |
| Voltage - Output 1 | 15 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 167.00 | |
Description
General part information
UIA700-15S
Enclosed AC DC Converters 1 Output 15V 90 ~ 264 VAC Input
