LP75W-12-P
ActiveEPtronics, Inc.
CV 12V@1563~6250MA, NON-DIMMING
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
LP75W-12-P
ActiveEPtronics, Inc.
CV 12V@1563~6250MA, NON-DIMMING
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | LP75W-12-P |
|---|---|
| Approval Agency | cULus, FCC, CE |
| Current - Output (Max) [Max] | 6.25 A |
| Dimming | Non-Dimmable |
| Efficiency | 84 % |
| Features | SCP, OCP, OVP |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 60 °C |
| Operating Temperature [Min] | -40 °C |
| Power (Watts) | 75 W |
| Ratings | IP67 |
| Size / Dimension [x] | 5.51 " |
| Size / Dimension [x] | 140 mm |
| Size / Dimension [y] | 59.2 mm |
| Size / Dimension [y] | 2.33 in |
| Size / Dimension [z] | 37.3 mm |
| Size / Dimension [z] | 1.47 in |
| Standard Number | C22.2, UL 8750 |
| Termination Style | Wire Leads |
| Topology | AC DC Converter |
| Type | Constant Voltage |
| Voltage - Input (Max) [Max] | 305 VAC |
| Voltage - Input (Min) [Min] | 100 VAC |
| Voltage - Isolation | 3750 V |
| Voltage - Output | 12 V |
| Weight | 1.25 lbs |
| Weight | 566.99 g |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 58.96 | |
Description
General part information
LP75W-12-P
6.25A 12V Constant Voltage LED Driver AC DC Converter Topology 1 Output
