MOX-2-132004FE
ActiveOhmite
RES 2M OHM 1% 3W AXIAL
Deep-Dive with AI
Search across all available documentation for this part.
MOX-2-132004FE
ActiveOhmite
RES 2M OHM 1% 3W AXIAL
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | MOX-2-132004FE |
|---|---|
| Composition | Thick Film |
| Features | High Voltage |
| Number of Terminations | 2 |
| Operating Temperature [Max] | 210 °C |
| Operating Temperature [Min] | -55 °C |
| Package / Case | Axial |
| Power (Watts) | 3 W |
| Resistance | 2 MOhms |
| Size / Dimension [diameter] | 0.31 in |
| Size / Dimension [diameter] | 7.87 mm |
| Size / Dimension [x] | 2.12 " |
| Size / Dimension [x] | 53.85 mm |
| Supplier Device Package | Axial |
| Temperature Coefficient | 50 ppm/°C |
| Tolerance | 1 % |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
MOX-2-132004FE
2 MOhms ±1% 3W Through Hole Resistor Axial High Voltage Thick Film
Documents
Technical documentation and resources
No documents available
