7123172C075
ActiveEase Electronics
CONN UHF PLUG 50 OHM RG213
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
7123172C075
ActiveEase Electronics
CONN UHF PLUG 50 OHM RG213
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 7123172C075 |
|---|---|
| Body Finish | Silver |
| Body Material | Brass |
| Cable Group | RG-213 |
| Center Contact Material | Brass |
| Center Contact Plating | Gold |
| Connector Style | UHF |
| Connector Type | Male Pin, Plug |
| Contact Termination | Crimp |
| Dielectric Material | Polytetrafluoroethylene (PTFE) |
| Frequency - Max [Max] | 200 MHz |
| Housing Color | Silver |
| Impedance | 50 Ohms |
| Mating Cycles | 500 |
| Mounting Type | Free Hanging (In-Line) |
| Number of Ports | 1 |
| Operating Temperature [Max] | 165 °C |
| Operating Temperature [Min] | -65 ░C |
| Shield Termination | Crimp |
| Voltage Rating | 500 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bag | 1 | $ 301.15 | |
| 10 | $ 236.43 | |||
| 25 | $ 216.03 | |||
Description
General part information
7123172C075
UHF Connector Plug, Male Pin 50 Ohms Free Hanging (In-Line) Crimp
