MPL02-05D05
ActiveP-DUKE Technology
ISOLATED / 2W / VOUT: 5
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MPL02-05D05
ActiveP-DUKE Technology
ISOLATED / 2W / VOUT: 5
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | MPL02-05D05 |
|---|---|
| Applications | ITE (Commercial), Medical |
| Approval Agency | CE, cURus, UKCA, CB |
| Mounting Type | Through Hole |
| Number of Outputs | 2 |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 5 Leads |
| Package / Case | 8-SIP Module |
| Power (Watts) | 2 W |
| Size / Dimension [x] | 0.86 in |
| Size / Dimension [x] | 21.8 mm |
| Size / Dimension [y] | 9.9 mm |
| Size / Dimension [y] | 0.39 " |
| Size / Dimension [z] | 0.49 in |
| Size / Dimension [z] | 12.5 mm |
| Standard Number | 60601-1, 62368-1 |
| Type | Isolated Module |
| Voltage - Input (Max) [Max] | 13.2 V |
| Voltage - Input (Min) [Min] | 4.5 V |
| Voltage - Isolation | 5000 V |
| Voltage - Output 1 | 5 V |
| Voltage - Output 2 | -5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 1 | $ 24.71 | |
| 10 | $ 21.72 | |||
| 25 | $ 20.63 | |||
| 50 | $ 19.84 | |||
| 100 | $ 19.09 | |||
| 250 | $ 18.13 | |||
| 500 | $ 17.44 | |||
Description
General part information
MPL02-05D05
Isolated Module DC DC Converter 2 Output 5V -5V 200mA, 200mA 4.5V - 13.2V Input
