PM202-12BN1
ActiveFSP Technology Inc.
AC/DC CONVERTER 12V 150W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
PM202-12BN1
ActiveFSP Technology Inc.
AC/DC CONVERTER 12V 150W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | PM202-12BN1 |
|---|---|
| Applications | ITE (Commercial), Medical |
| Approval Agency | cURus, TUV, UL, CE |
| Current - Output 1 | 12.5 A |
| Efficiency | 91 % |
| Features | Adjustable Output, Universal Input |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | 0 °C |
| Power (Watts) | 150 W |
| Size / Dimension [x] | 5 in |
| Size / Dimension [x] | 127 mm |
| Size / Dimension [y] | 3 " |
| Size / Dimension [y] | 76.2 mm |
| Size / Dimension [z] | 38.1 mm |
| Size / Dimension [z] | 1.5 " |
| Standard Number | 60601-1, 62368-1 |
| Type | Open Frame |
| Voltage - Input [Max] | 264 VAC |
| Voltage - Input [Min] | 90 VAC |
| Voltage - Output 1 | 12 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 99.30 | |
| 5 | $ 96.82 | |||
| 10 | $ 93.84 | |||
| 25 | $ 89.87 | |||
Description
General part information
PM202-12BN1
Open Frame AC DC Converters 1 Output 12V 90 ~ 264 VAC Input
