PCSV65-2R2T-RC
ActiveAllied Components International
2.2H 30% SHIELDED POWER CHIP IND
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
PCSV65-2R2T-RC
ActiveAllied Components International
2.2H 30% SHIELDED POWER CHIP IND
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | PCSV65-2R2T-RC |
|---|---|
| Current - Saturation (Isat) | 8.8 A |
| Current Rating (Amps) | 5.1 A |
| DC Resistance (DCR) | 18.4 mOhm |
| Height - Seated (Max) | 4.5 mm |
| Height - Seated (Max) [Max] | 0.177 " |
| Inductance | 2.2 µH |
| Inductance Frequency - Test | 100 kHz |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 125 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Nonstandard |
| Shielding | Shielded |
| Size / Dimension [x] | 0.236 in |
| Size / Dimension [x] | 6 mm |
| Size / Dimension [y] | 0.236 in |
| Size / Dimension [y] | 6 mm |
| Tolerance | 30 % |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tape & Reel (TR) | 1 | $ 0.98 | |
| 5 | $ 0.85 | |||
| 10 | $ 0.80 | |||
| 15 | $ 0.75 | |||
Description
General part information
PCSV65-2R2T-RC
2.2 µH Shielded Inductor 5.1 A 18.4mOhm Nonstandard
