B5812-01
ObsoleteAntenova
RF ANT 800MHZ/900MHZ MOLDED SMA
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
B5812-01
ObsoleteAntenova
RF ANT 800MHZ/900MHZ MOLDED SMA
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | B5812-01 |
|---|---|
| Antenna Type | Molded |
| Applications | GSM |
| Frequency (Center/Band) | 900 MHz, 800 MHz, 1.9 GHz, 1.8 GHz |
| Frequency Range [Max] | 1.99 GHz, 960 MHz |
| Frequency Range [Min] | 880 MHz, 1.71 GHz |
| Height (Max) | 0.152 in |
| Height (Max) | 3.85 mm |
| Mounting Type | Snap-In |
| Number of Bands | 4 |
| RF Family/Standard | Cellular |
| VSWR | 1.2, 1 |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
B5812-01
RF ANTENNA GSM Molded SMA Male Snap-In
