611-51001 - FS/FE 10-RL-NS-E4
ActiveSensoPart
THROUGH-BEAM LASER SENSOR
Deep-Dive with AI
Search across all available documentation for this part.
611-51001 - FS/FE 10-RL-NS-E4
ActiveSensoPart
THROUGH-BEAM LASER SENSOR
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | 611-51001 - FS/FE 10-RL-NS-E4 |
|---|---|
| Adjustment Type | Teaching Method |
| Connection Method | Connector, M5 |
| Ingress Protection | IP67 |
| Light Source | Red (655nm) |
| Operating Temperature [Max] | 50 °C |
| Operating Temperature [Min] | -20 C |
| Output Configuration | NPN |
| Response Time | 125 µs |
| Sensing Distance | 4 m |
| Sensing Distance | 13.12 ft |
| Sensing Method | Through-Beam |
| Voltage - Supply [Max] | 30 VDC |
| Voltage - Supply [Min] | 10 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Retail Package | 1 | $ 208.00 | |
Description
General part information
611-51001 - FS/FE 10-RL-NS-E4
Through-Beam Optical Sensor 13.12' (4m) NPN
Documents
Technical documentation and resources
No documents available
