WNA10RFE
ActiveOhmite
RES 10 OHM 1% 1/2W AXIAL
Deep-Dive with AI
Search across all available documentation for this part.
WNA10RFE
ActiveOhmite
RES 10 OHM 1% 1/2W AXIAL
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | WNA10RFE |
|---|---|
| Composition | Wirewound |
| Features | Non-Inductive |
| Number of Terminations | 2 |
| Operating Temperature [Max] | 150 °C |
| Operating Temperature [Min] | -55 °C |
| Package / Case | Axial |
| Power (Watts) | 0.5 W |
| Power (Watts) | 0.5 W |
| Resistance | 10 Ohms |
| Size / Dimension | 5.08 mm, 2.54 mm |
| Size / Dimension [diameter] | 0.1 " |
| Size / Dimension [z] | 0.2 " |
| Supplier Device Package | Axial |
| Temperature Coefficient | 50 ppm/°C |
| Tolerance | 1 % |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
WNA10RFE
10 Ohms ±1% 0.5W, 1/2W Through Hole Resistor Axial Non-Inductive Wirewound
Documents
Technical documentation and resources
No documents available
