AMEL15-24SJZ
Activeaimtec
AC/DC CONVERTER 24V 15W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
AMEL15-24SJZ
Activeaimtec
AC/DC CONVERTER 24V 15W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | AMEL15-24SJZ |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | CE, cURus |
| Current - Output (Max) [Max] | 625 mA |
| Efficiency | 81 % |
| Features | Universal Input |
| Line Regulation | 0.5 % |
| Load Regulation | 1 % |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 4-DIP Module |
| Power (Watts) | 15 W |
| Size / Dimension [x] | 53.8 mm |
| Size / Dimension [x] | 2.12 " |
| Size / Dimension [y] | 1.13 in |
| Size / Dimension [y] | 28.8 mm |
| Size / Dimension [z] | 0.93 in |
| Size / Dimension [z] | 23.5 mm |
| Type | Enclosed |
| Voltage - Input [Max] | 264 VAC, 370 VDC |
| Voltage - Input [Min] | 100 V, 85 VAC |
| Voltage - Output 1 | 24 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 13.14 | |
| 5 | $ 12.96 | |||
| 10 | $ 12.78 | |||
| 25 | $ 12.41 | |||
| 50 | $ 11.68 | |||
| 100 | $ 11.32 | |||
| 250 | $ 10.99 | |||
| 500 | $ 10.63 | |||
Description
General part information
AMEL15-24SJZ
Enclosed AC DC Converters 1 Output 24V 625mA 85 ~ 264 VAC, 100 ~ 370 VDC Input
