NSC5083D-49.152M
ActiveNDK America, Inc.
OSC XO 49.152MHZ CMOS 3.3V SMD
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
NSC5083D-49.152M
ActiveNDK America, Inc.
OSC XO 49.152MHZ CMOS 3.3V SMD
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | NSC5083D-49.152M |
|---|---|
| Base Resonator | Crystal |
| Current - Supply (Disable) (Max) [Max] | 35 µA |
| Current - Supply (Max) [Max] | 15 mA |
| Frequency | 49.152 MHz |
| Frequency Stability | 50 ppm |
| Function | Standby (Power Down) |
| Height - Seated (Max) [Max] [z] | 0.035 " |
| Height - Seated (Max) [Max] [z] | 0.9 mm |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Output | CMOS |
| Package / Case | 4-SMD, No Lead |
| Size / Dimension [x] | 0.098 " |
| Size / Dimension [x] | 2.5 mm |
| Size / Dimension [y] | 2 mm |
| Size / Dimension [y] | 0.079 in |
| Type | XO (Standard) |
| Voltage - Supply | 3.3 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 3.00 | |
| 10 | $ 2.59 | |||
| 50 | $ 2.34 | |||
| 100 | $ 2.24 | |||
| 500 | $ 2.02 | |||
| 1000 | $ 1.93 | |||
| Digi-Reel® | 1 | $ 3.00 | ||
| 10 | $ 2.59 | |||
| 50 | $ 2.34 | |||
| 100 | $ 2.24 | |||
| 500 | $ 2.02 | |||
| 1000 | $ 1.93 | |||
| Tape & Reel (TR) | 3000 | $ 1.80 | ||
Description
General part information
NSC5083D-49.152M
49.152 MHz XO (Standard) CMOS Oscillator 3.3V Standby (Power Down) 4-SMD, No Lead
