KRG0600010IBY
ActiveThinking Electronics Industrial Co.
POLYMER PTC RESETTABLE FUSE 60V
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
KRG0600010IBY
ActiveThinking Electronics Industrial Co.
POLYMER PTC RESETTABLE FUSE 60V
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | KRG0600010IBY |
|---|---|
| Approval Agency | cUL, TUV, UL |
| Current - Hold (Ih) (Max) [Max] | 100 mA |
| Current - Max [Max] | 40 A |
| Current - Trip (It) | 200 mA |
| Height - Seated (Max) [Max] [z] | 12.7 mm |
| Height - Seated (Max) [Max] [z] | 0.5 in |
| Lead Spacing | 5 mm |
| Lead Spacing | 0.197 in |
| Mounting Type | Through Hole |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | Disc, Radial |
| Resistance - 25°C (Typ) | 4.5 Ohms |
| Resistance - Initial (Ri) (Min) [Min] | 2.5 Ohms |
| Resistance - Post Trip (R1) (Max) [Max] | 7.5 Ohms |
| Size / Dimension [diameter] | 0.291 in |
| Size / Dimension [diameter] | 7.4 mm |
| Size / Dimension [z] | 0.118 " |
| Size / Dimension [z] | 3 mm |
| Time to Trip | 4 s |
| Type | Polymeric |
| Voltage - Max [Max] | 60 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bag | 1 | $ 2.50 | |
| 5 | $ 2.25 | |||
| 10 | $ 1.98 | |||
| 15 | $ 1.85 | |||
Description
General part information
KRG0600010IBY
Polymeric PTC Resettable Fuse 60V 100 mA Ih Through Hole Radial, Disc
