AB-D2050-V24-Q
ActiveAmerican Bright Optoelectronics Corporation
110VAC INPUT, 24VDC OUPUT, 50W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
AB-D2050-V24-Q
ActiveAmerican Bright Optoelectronics Corporation
110VAC INPUT, 24VDC OUPUT, 50W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | AB-D2050-V24-Q |
|---|---|
| Approval Agency | cULus, cURus |
| Current - Output (Max) [Max] | 2.08 A |
| Dimming | TRIAC |
| Efficiency | 88 % |
| Features | OTP, SCP, OVP, OCP |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 45 °C |
| Operating Temperature [Min] | -20 C |
| Power (Watts) | 50 W |
| Ratings | IP20 |
| Size / Dimension [x] | 156 mm |
| Size / Dimension [x] | 6.14 in |
| Size / Dimension [y] | 1.97 " |
| Size / Dimension [y] | 50 mm |
| Size / Dimension [z] | 17 mm |
| Size / Dimension [z] | 0.67 in |
| Standard Number | UL 8750 |
| Termination Style | Screw Terminal |
| Topology | AC DC Converter |
| Type | Constant Voltage |
| Voltage - Input (Max) [Max] [custom] | 132 VAC |
| Voltage - Input (Min) [Min] | 90 VAC |
| Voltage - Output | 24 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 23.99 | |
| 5 | $ 22.72 | |||
| 10 | $ 21.46 | |||
| 25 | $ 20.52 | |||
| 50 | $ 19.57 | |||
| 100 | $ 18.94 | |||
| 250 | $ 17.36 | |||
| 500 | $ 17.04 | |||
Description
General part information
AB-D2050-V24-Q
2.08A 24V Constant Voltage LED Driver AC DC Converter Topology 1 Output
