AP10S277LH
ActiveABLE Power Products
SPD 320V MCOV 1 POLE
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
AP10S277LH
ActiveABLE Power Products
SPD 320V MCOV 1 POLE
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | AP10S277LH |
|---|---|
| Current - Discharge (Max) (8/20µS) [Max] | 25 kA |
| Current - Discharge (Nom) (8/20µS) | 10 kA |
| Features | Thermally Protected, Visual Life Indicator |
| Form | Module Only |
| Mounting Type | Chassis Mount |
| Number of Poles | 1 |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -40 °C |
| Voltage - Continuous Operating (Max) (MCOV) [Max] | 320 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 20.00 | |
| 10 | $ 18.60 | |||
| 25 | $ 17.30 | |||
| 100 | $ 16.09 | |||
| 250 | $ 14.96 | |||
| 500 | $ 13.91 | |||
| 1000 | $ 12.94 | |||
Description
General part information
AP10S277LH
SPD 320V MCOV 1 POLE
Documents
Technical documentation and resources
