OWS-2879W50A-4
ActiveOle Wolff Electronics Inc
SPEAKER 4OHM 2W TOP PORT 103DB
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
OWS-2879W50A-4
ActiveOle Wolff Electronics Inc
SPEAKER 4OHM 2W TOP PORT 103DB
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | OWS-2879W50A-4 |
|---|---|
| Distortion Rating | 10 % |
| Efficiency - dBA | 103 dBA |
| Efficiency - Testing | 2W/10cm |
| Efficiency - Type | Sensitivity |
| Frequency - Self Resonant | 570 Hz |
| Frequency Range [Max] | 20 kHz |
| Frequency Range [Min] | 100 Hz |
| Height - Seated (Max) [Max] [z] | 0.311 in |
| Height - Seated (Max) [Max] [z] | 7.9 mm |
| Impedance | 4 Ohms |
| Ingress Protection | IP67 - Dust Tight, Waterproof |
| Material - Cone [custom] | Plastic |
| Material - Magnet | Nd-Fe-B |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -30 ░C |
| Port Location | Top |
| Power - Max [Max] | 3 W |
| Power - Rated | 2 W |
| Shape | Round |
| Size / Dimension [diameter] | 1.102 in |
| Size / Dimension [diameter] | 28 mm |
| Technology | Magnetic |
| Termination | Wire Leads |
| Type | General Purpose |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 1.86 | |
| 10 | $ 1.52 | |||
| 25 | $ 1.40 | |||
| 40 | $ 1.34 | |||
| 80 | $ 1.26 | |||
| 230 | $ 1.15 | |||
| 440 | $ 1.09 | |||
| 945 | $ 1.02 | |||
| 4900 | $ 0.96 | |||
Description
General part information
OWS-2879W50A-4
4 Ohms General Purpose Speaker 2 W 100 Hz ~ 20 kHz Top Round
