S3L-353113
ActiveNew Age Enclosures
BOX ABS BLACK 3.50"L X 3.10"W
Deep-Dive with AI
Search across all available documentation for this part.
S3L-353113
ActiveNew Age Enclosures
BOX ABS BLACK 3.50"L X 3.10"W
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | S3L-353113 |
|---|---|
| Area (L x W) | 70 cm² |
| Area (L x W) | 10.9 in² |
| Color | Black |
| Container Type | Box |
| Design | Cover Included, Hand Held |
| Height [z] | 33.02 mm |
| Height [z] | 33.02 mm |
| Material | Plastic, ABS |
| Size / Dimension [x] | 3.504 in |
| Size / Dimension [x] | 89 mm |
| Size / Dimension [y] | 3.104 in |
| Size / Dimension [y] | 78.84 mm |
| Thickness | 1.52 mm |
| Thickness | 0.06 in |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bag | 1 | $ 12.82 | |
| 5 | $ 10.96 | |||
| 10 | $ 10.24 | |||
| 25 | $ 9.36 | |||
| 50 | $ 8.75 | |||
| 100 | $ 8.18 | |||
| 250 | $ 7.76 | |||
Description
General part information
S3L-353113
Box Plastic, ABS Black Hand Held, Cover Included 3.504" L x 3.104" W (89.00mm x 78.84mm) X 1.300" (33.02mm)
Documents
Technical documentation and resources
No documents available
