VSEB0730H-4R7MC
ActiveCODACA
FIXED IND 4.7UH 6.8A 23.9MOHM SM
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
VSEB0730H-4R7MC
ActiveCODACA
FIXED IND 4.7UH 6.8A 23.9MOHM SM
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | VSEB0730H-4R7MC |
|---|---|
| Current - Saturation (Isat) | 6.8 A |
| DC Resistance (DCR) [Max] | 23.9 mOhm |
| Features | Molded Inductors, Automotive Grade Power Inductors |
| Height - Seated (Max) | 3 mm |
| Height - Seated (Max) [Max] | 0.118 in |
| Inductance | 4.7 ÁH |
| Inductance Frequency - Test | 100 kHz |
| Material - Core | Alloy Powder |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 155 °C |
| Operating Temperature [Min] | -55 °C |
| Package / Case | Nonstandard |
| Ratings | AEC-Q200 |
| Shielding | Shielded |
| Size / Dimension [x] | 7.9 mm |
| Size / Dimension [x] | 0.311 " |
| Size / Dimension [y] | 7.6 mm |
| Size / Dimension [y] | 0.299 in |
| Tolerance | 20 % |
| Type | Molded |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 2.42 | |
| 10 | $ 2.06 | |||
| 25 | $ 1.90 | |||
| 50 | $ 1.70 | |||
| 100 | $ 1.41 | |||
| 250 | $ 1.37 | |||
| 500 | $ 1.29 | |||
| Digi-Reel® | 1 | $ 2.42 | ||
| 10 | $ 2.06 | |||
| 25 | $ 1.90 | |||
| 50 | $ 1.70 | |||
| 100 | $ 1.41 | |||
| 250 | $ 1.37 | |||
| 500 | $ 1.29 | |||
| Tape & Reel (TR) | 1000 | $ 1.08 | ||
| 2000 | $ 1.00 | |||
| 3000 | $ 1.00 | |||
Description
General part information
VSEB0730H-4R7MC
4.7 µH Shielded Molded Inductor 23.9mOhm Max Nonstandard Molded Inductors, Automotive Grade Power Inductors
