CN050M330F10PE50V00R
ActiveSuscon
CAP ALUM 33UF 20% 50V SMD
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
CN050M330F10PE50V00R
ActiveSuscon
CAP ALUM 33UF 20% 50V SMD
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | CN050M330F10PE50V00R |
|---|---|
| Applications | General Purpose |
| Capacitance | 33 ÁF |
| Height - Seated (Max) [Max] | 0.394 in |
| Height - Seated (Max) [Max] | 10 mm |
| Lifetime @ Temp. | 1000 Hrs |
| Mounting Type | Surface Mount |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -55 °C |
| Package / Case | Radial, Can - SMD |
| Polarization | Bi-Polar |
| Ripple Current @ High Frequency | 135 mA |
| Ripple Current @ Low Frequency | 90 mA |
| Size / Dimension [diameter] | 0.315 " |
| Size / Dimension [diameter] | 8 mm |
| Surface Mount Land Size [x] | 0.327 " |
| Surface Mount Land Size [x] | 8.3 mm |
| Surface Mount Land Size [y] | 8.3 mm |
| Surface Mount Land Size [y] | 0.327 in |
| Tolerance | 20 % |
| Voltage - Rated | 50 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tape & Reel (TR) | 5 | $ 0.35 | |
| 50 | $ 0.28 | |||
| 100 | $ 0.25 | |||
| 500 | $ 0.19 | |||
| 1000 | $ 0.19 | |||
Description
General part information
CN050M330F10PE50V00R
33 µF 50 V Aluminum Electrolytic Capacitors Radial, Can - SMD 1000 Hrs @ 85°C
